Specifications

24 Volt System
(10) Gel-cell 12V 8D house batteries
(4) Gel-cell 12V 8D engine batteries
(3) Gel-cell 12V Group 27 Generator engine batteries
RATELCO 12V 15amp automatic battery charger
(3) NORTHERN LIGHTS generators, all with 12V belt driven alternators/90k, 74kw, 40kw
Port, starboard and aft generator engines fitted with single RACOR fuel filters/water separators mounted on steel stanchions adjacent to generator sets
3-phase 208 volt converts to 250v
(2) 100amp AC shore power inlets
90' 100amp 250V AC shore power cord
SEA TEL model #DAC 2200 antenna unit
TRIPP LITE surge suppressor
(5) Vapor battery selector rotary switches;(1) for each main engine and (1) for each generator engine
Main breaker fitted on circuit breaker panel
Individual switch branch breakers located in main AC panel in aft engine room
120V AC Ammeter and voltmeter on 120V AC breaker panel board
All Sea Power Transformer

NAIAD hydraulic anti-roll stabilizer system
AMERICAN bow thruster
Air-conditioning with heating
(3) HUBBELL 115 electric hot water tanks; 80 gals each
(6) RULE 2000 GPH 24V bilge pumps with automatic float switches
DAYTON 3hp 230V AC bilge pumps
Mechanical fuel and air shut off controls for both engines
DAYTON 208V AC/230V AC 9hp fuel
Fuel system is fitted with "Alfa Laval"
Low oil pressure alarm and coolant overheat warning audible at helm station
Triple RACOR fuel and water filter separators for main engines mounted in engine room forward of port and starboard engines
RA TELCO 12V 15amp automatic battery charger mounted on electrical switch board panel in engine room

SPECIFICATIONS
